TL;DR โ Quick Answer
Every AXOSPRO machine is configured for North American electrical service โ 110-120 V with a NEMA plug โ and the exact voltage, plug type and rated power for each model is on its product page. The failure that catches most buyers is not voltage at all: it is compressor startup surge tripping a breaker that looks large enough on paper.
- Service: Every model configured for North American electrical service
- Plug: NEMA plug; 220 V configurations available on request
- What trips breakers: Compressor startup surge, and shared circuits
- Before you order: Compare rated power on the product page against your circuit
Voltage is rarely the problem. Surge is.
Buyers worry about 110 V versus 220 V, and then the machine arrives, plugs in, and trips the breaker on the second start. Voltage was never the issue.
When a compressor starts it draws several times its running current for a second or two. A breaker sized to the running load will hold the machine once it is going and will trip every time it starts. The other half of the problem is shared circuits: a soft serve machine on the same circuit as a fridge and a coffee machine will trip when all three compressors happen to start together, and none of them is individually over the limit.
The fix in both cases is electrical, not mechanical โ a dedicated circuit of the correct rating.
Reading the rating plate
| Field | What it tells you | What to do with it |
|---|---|---|
| Voltage | The service the machine is built for | Must match your supply exactly |
| Frequency (Hz) | 60 Hz in North America | A 50 Hz machine on 60 Hz service will not run correctly |
| Rated power / current | Continuous load | What the circuit must carry |
| Plug type | What it physically connects to | Confirms whether you need an electrician |
| Refrigerant | What the system is charged with | Service information โ tell your technician |
Every AXOSPRO product page lists the electrical specification for North America, so this can all be checked before you order rather than discovered on delivery day.
The one extra check for ice makers
Everything above applies to ice makers too, with one addition: they are the machines in the AXOSPRO range that need plumbing as well as power.
A commercial ice maker takes a potable cold water supply through an inlet line, and discharges melt and rinse water through a separate drain line. Two connections, not one. If your premises has no floor drain at the right height, that is a bigger problem than the electrical side, and it is worth resolving before the machine ships. Our ice machine installation requirements guide covers it in full.
Soft serve, slush, popsicle and fried ice cream machines have none of this โ the mix is poured in by hand, so there is no water line and no drain.
Related guides
- Ice machine installation requirements
- Power for a food truck or small shop
- Can you run one at home?
- Warranty and service
Frequently asked questions
Do commercial ice cream machines run on 110V or 220V?
Every AXOSPRO machine is configured for North American electrical service, and the specific voltage, plug type and rated power for each model is listed on its product page. In North America that means standard 110-120 V service with a NEMA plug for the machines in the range, with 220 V configurations available on request for buyers outside North America or with three-phase premises.
Can I run a soft serve machine on a standard outlet?
Check the rated power and plug type on the product page against the circuit you plan to use. A machine that arrives with a NEMA plug for North American service will physically fit a standard receptacle, but whether that circuit can hold it depends on what else is on the same circuit and on the compressor startup surge, which is several times the running current for the first second or two.
Why does my machine trip the breaker?
Almost always because of compressor startup surge or because the circuit is shared. A compressor draws several times its running current for a moment when it starts, and a breaker sized to the running load will trip on that surge. Sharing the circuit with anything else that cycles โ a fridge, an ice maker, a coffee machine โ compounds it. The fix is a dedicated circuit of the right rating, not a bigger machine.
Do I need an electrician to install a commercial ice cream machine?
For a machine that arrives with a standard plug for your service, usually not โ but have the circuit checked if the machine will share it with other equipment, or if the machine is going into a space where the wiring is old. For any model that requires a dedicated circuit or a hardwired connection, use a licensed electrician, and check whether your local code requires one either way.
What is on the rating plate?
Voltage, frequency in hertz, rated current or power, and often the refrigerant charge. Voltage and frequency must match your service exactly. Rated power tells you what the circuit has to carry continuously. If you are comparing machines, compare rated power at the same voltage โ a machine that looks more powerful may simply be specified for a different service.
Do the ice makers need a different electrical setup?
The cube ice makers and flake ice machines carry the same North American electrical configuration as the rest of the range, but they are the machines that also need plumbing. They take a potable cold water supply through an inlet line and discharge melt and rinse water through a separate drain line โ two connections, not one. Full details are in our ice machine installation requirements guide.
